5.00/
DESCRIPTION
AC/DC Output for T5 or T8 lamps
One- or Two-lamp Operation
Up to 3500 Lumen Output
Universal Input (120 through 277)
UL Listed for the US and Canada
Factory or Field Installation
(Indoor and Damp)
Illumination Time
90 Minutes
Initial Light Output
900 - 3500 Lumens
Full Warranty
5 Years (NOT pro-rata)
Universal Input Voltage
120-277 VAC, 50/60 Hz
AC Input Current
110 mA
AC Input Power Rating
8.5 Watts
Test Switch/Charging Indicator Light
Two-Wire Illuminated Test Switch (2W-ITS)
Battery
High-Temperature, Maintenance-Free
Nickel-Cadmium Battery 7- to 10-Year Life Expectancy
Battery Charging Current
280 mA
Recharge Time
24 Hours
Temperature Rating (Ambient)
0°C to +50°C
(32°F to 122°F)
Dimensions
16.6” x 2.8” x 2.85”
(422 mm x 71 mm x 73 mm)
2’ (610 mm) Flexible Conduit
Mounting Center 16.05” (408mm)
Benefits:
- Emergency mode lumen output up to 3500 lumens
- AC or DC output for T5 or T8 lamps
- Operates TLED lamps (See Table 1)
- One- or Two-lamp operation
- Universal input (120 through 277 VAC 50/60 Hz)
- End-of-Lamp Life Compatible
- Two-wire illuminated test switch
